X252

External Interface Control Board

The External Control Interface Board is an optional item that allows users to set up GCC laser machines for communication with external devices such as odor reduction units, robot arms and others via a 5V or 12V signal to form an automatic production line. Another useful practice applies in certain working environments when users are required to set up an extra remote interlock control or when laser machines are allowed to be switched off if a security device is triggered.

AAS Contour Cutting Device (Patented)

Developed by GCC LaserPro, AAS is an exceptionally user-friendly operation which offers accurate and faultless contour cutting by automatically tracking the position of graphics.
Note: Working area and engraving speed will be reduced when AAS module is installed.

SmartBOX™

An innovative technology that integrates the ventilation box with a honeycomb table or Aluminum grid cutting table. The result is not only a precise cut with sharp edges, but also a clean laser table to work on.

Rotary Attachment

Allows the laser system to perform at another level! By using the rotary attachment, engraving on cylindrical or round objects is now possible. This option uses a fourth axis to rotate your object 360° to allow engraving on cups, wine glasses or even a baseball with two types of conical fixture available. The minimum/maximum diameter and length of the working object is 90/180mm and 450mm respectively. Its maximum weight should not exceed 4kgs.
*Please note that the Rotary Attachment is not able to work with AAS module at the same time.

SmartAIR™ Fine Nozzle

The optional SmartAIR Fine Nozzle is recommended for engraving or cutting thin materials such as textile. The smaller caliber nozzle is positioned closer to the object for a concentrated blast directed over a small area to eliminate burning on the cutting edge. The perfectly-vertical design of the SmartAIR Fine Nozzle produces a concentrated airflow to blow away dust and unwanted residue, leaving a clean product surface.

Purex Fume Extraction System

GCC teams up with a UK company to offer the Purex fume extraction unit for its full-line LaserPro laser engraving and cutting systems. These Fume Extraction Systems are specifically designed to prevent personnel from inhaling hazardous fumes and dust generated during the process. Applicable to all GCC LaserPro engravers, the Purex Fume Extraction System represents the latest invention in the exhaust extraction and smoke reduction technology for all types of applications. Noise-free operation, high vacuum capacity, compact design and long life expectancy are just a few of its outstanding features. Powered by a maintenance-free, continuous-running turbine, the Fume Extraction System, which is CE-compliant, ensures personnel safety and legal compliance.

Air Compressor

A specially designed Air Compressor for laser engravers, by using an oil-less diaphragm, you help eliminate the harmful and damaging side effects of moisture on the laser optics. Also, provides the optimal air pressure your laser needs to blow away vaporized particles and helps prevents overheating. A must to keep lenses and mirrors clean to promote longer laser life.

SmartGUARD™ Fire Alarm (Patented)

Laser cutting and engraving operation using the SmartGUARD Fire Alarm assures optimum safety. When there is a malfunction, the alarm system will be active and shut-down the operation system immediately.

Honeycomb Table

The honeycomb table is an ideal tool for laser cutting, especially when cutting materials into small pieces. It lifts the work piece off the work table from hitting by laser reflection while supports it with honeycomb cell design. The dust and vapor created during laser cutting are then taken away effectively through the honeycomb cell by down vacuum funnel exhaust. Rather than handling rigid materials, honeycomb table also helps to fix flexible materials with the aid of down vacuum to keep constant focus distance and consistent cutting result. A clean and better cutting quality is achieved from this technique.

*Speed is not equal to throughput. See dealer or visit www.GCCworld.com for more details.
Specifications are subject to change without prior notice.
*The flow rate is determined by a default fume extraction system; the flow rate may vary due to a di fferent fume extraction system.​

Warranty Policy is Effective from 01/01/2019

GCC, a global forefront equipment-manufacturing provider in the visual communication industry, is pleased to announce New Product Warranty Policy. The warranty period for new qualifying machine purchases will be counted from Installation Date provided the following conditions are met.

The condition and workflow have been displayed below :

1. New Product Warranty Policy is applied to machine shipped from GCC in 2019.
2. When the machine sold to end user, it is important to advise end user immediately to link to the GCC’s club http://gccf.gcc.com.tw/gccclub/login.aspx  to sign up and input the machine Serial number and their basic data to activate the machine warranty. Then the warranty of this specific serial number of machine will be changed from the invoice date to data input date (i.e., Purchasing Date that end-user purchases machine)
3. However, the max. Periods for end user to activate the machine warranty is 180 calendar days from invoice date.  If machine fails to be registered within this 180 days period, there will be no any extended warranty and the machine warranty period will be by default still from the invoice date.
4. Warranty for Consumable item, Optional item and Spare parts are counted from GCC Invoice Date without change.

GCC You Tube Video Demo link:  Laser Engraved- Logo Transformers GCC Laserpro X252

GCC You Tube Video Demo link:  A Gcc x252 Laserpro. Bought as Scrap, Rebuild.

GCC You Tube Video Demo link:   Cleaning Mirror 1 on GCC Laser Pro X 252 (part 1)

GCC You Tube Video Demo link:  Cleaning Mirror  1 on GCC Laser Pro X252 ( part 2)

GCC You Tube Video Demo link:  Cleaning Mirror 2-3 on GCC Laser Pro X252 ( part 3 )

GCC You Tube Video Demo link:   Cleaning Lens and Bed. Extraction Unit Maintenance on GCC Laser Pro X252 (part 4)

GCC You Tube Video Demo link:  Replacing water in cooling unit on GCC laser pro X252 (part 5)

GCC You Tube Video Demo link:  Safe operation and start up procedure of GCC laser pro X252 (part 6)

GCC You Tube Video Demo link:  Setting material size on driver using 2D Design on GCC X252 laser pro ( part 7)

GCC You Tube Video Demo link:  Settings for driver using 2D Design on GCC laser pro X252( part 8)

GCC You Tube Video Demo link:   Photograph engrave using 2D Design on GCC laser pro X252 (Part 9).

GCC You Tube Video Demo link:   Operations checklist on GCC laser pro X252 (Part 10)
